SUMMARY
THEROTICAL REPORT
Robotic rover consists of several sensors and cooling modules operating with Arduino uno R3 development board works obstically and controls by electronic devices through HC-05 bluetooth module having maximum 38400 baud rate and will further consists of esp32cam / huskeylens ai thinker camera module and raspberry pi 1 A+ GRADE will be used furtherly .
NOTE: This project is under development and the bot is currently at level 1 position respectively.
PRATICAL WELDINNG IMAGES OF BASE STEM
NEW ADDITIONAL INSTULMENTS INSTALLATION IMAGES
30%
temperature display
95%
BMS WORKING CONDITION
77%
Robotics operating processes
89%
microcontroller efficiency
20%
sensor working percentage
0.7%
errors
RASPBERRY PI 1 A+ GRAGE SMALL COMPUTER ESP 32 CAMERA AI FACE DETECTION W1219 TEMPRATURE CONTROLLER
MICROCONTROLOLER AT LEVEL-3 MODULE AT LEVEL-2 MODULE AT KLEVEL-2
